Model, size customization
Multiple display surfaces
Model(mm): P2.5 ，P4
APEXLS LED cubes are seamlessly spliced, 360° viewing angle with unique shape, gorgeous effect, great visual viewing and commercial value. The screen body can be designed as a mechanical rotating device around the axis, too.
Museums, planetariums, science and technology museums, children’s palaces, exhibition halls, gymnasiums, etc.
The led cube has a wide viewing angle, without distortion or color distortion. it is easy to display stereoscopic images by playing custom video sources. It supports Wifi/4G/5G/USB control (optional), and supports advertising release, update, management and other tasks.
Based on our rich experience in designing customized display with irregular shapes, we optimized the inner structure and module bottom shell of led cube to ensure the minimum joint of the display surface, in order to achieve the best display effect.
High color uniformity and clear image can bring you a vivid audio visual effect.The LED Chips that we use have the advantages of large viewing angle, low power consumption and good color uniformity
Six display faces can show six kinds of different content respectively or work as a whole to show the same video. Led cube has special shapes and can also be used as high-tech artworks to decorate the environment.
| KC Series Cube LED Display | ||
| Model | P2.5 | P4 |
| Pixel Pitch(mm) | 2.5 | 4 |
| LED Type | SMD1515 | SMD2121 |
| Pixel Density(dots/㎡) | 160000 | 62500 |
| Viewing Distance(m) | 2.5 | 4 |
| Brightness(cd/㎡) | ≥1200 | ≥1500 |
| Avg Power Consumption(W/㎡) | 200-250 | 250-300 |
| Max Power Consumption(W/㎡) | 520 | 620 |
| Refresh Rate(Hz) | 4096 | |
| Input Voltage | AC100-240V/50-60Hz | |
| Life Span | 100,000 hours | |
| Package | Flight case or Wooden case | |
| Certification | CE/RoHs/ETL | |
| Supplier Type | Original manufacturer, ODM,OEM | |
